Porshe 911 (997). Manual - part 1018





Installation position

Unclipping control unit

1. Unclip control unit from the holder

-A-

 .

Releasing electric connector

Diagnostic system: reading out fault memory and activating systems

Removing control unit for garage door opener/HomeLink

4230

2. Release electric connector -A- and remove it from control unit.

Installing control unit for garage door opener/HomeLink

Installing control unit for garage door opener/HomeLink

1. Push electric connector onto control unit until it is felt to

engage.

Engaging and clipping in control unit

2. Engage and clip control unit into

holder.

Subsequent work

Subsequent work for control unit for garage door opener/HomeLink

Installing front apron. → 631519 Removing and installing front apron - section on "Installing"

Teaching control unit for garage door opener/HomeLink

Diagnostic system: reading out fault memory and activating systems

 Installing control unit for garage door opener/HomeLink

4231

HomeLink

WARNING

Danger of accidents if persons, animals or objects lie in the swinging range of the controlled mechanism
during operation of the garage door opener.

→ Ensure that there are no persons, animals or objects in the swinging range of the controlled mechanism

during operation of the garage door opener.

→ Observe the safety instructions for the original hand-held transmitter.

The programmable HomeLink replaces up to three original remote controls for operating various equipment
(e.g. garage door, gate to property, alarm system).

Overview of button assignment for garage door opener

The buttons -1 to 3- can be programmed with a frequency of an original remote control.
Prerequisites for operating and programming the HomeLink:

–  The ignition is switched on.

–  The fog lights are switched off.

To activate the required equipment:
Press the relevant button -1, 2 or 3- . The LED -A- lights up during signal transmission.
Operating instructions:
Always use the garage door opener in the direction of travel. Otherwise range limitations cannot be ruled out.
Before selling the vehicle, erase the programmed garage door opener signals on the keypad.
To determine whether the original remote control has a fixed or variable code, please read the instructions for
the original remote control.
In the case of a standard fixed code, the LED in the roof console is permanently lit during the transmission
process. No further steps are necessary for the operation of compatible systems.
If the system set is not activated by the garage door opener control unit, this may be because the original
remote control has a variable code.

Assigning garage door opener/HomeLink signals to buttons

Diagnostic system: reading out fault memory and activating systems

HomeLink

4232
