Porshe 911 (997). Manual - part 1003

Luggage compartment light overview

D

- Luggage compartment light

Removing luggage compartment light

1. Press luggage compartment light carefully out of the luggage compartment trim at the cutout

-arrow-

 using a screwdriver.

2. Pull off plug on luggage compartment light and remove luggage compartment light.

Removing bulb for light

Diagnostic system: reading out fault memory and activating systems

Removing luggage compartment light

4169

Removing bulb for light

1. Remove defective bulb from between the contact springs.

Installing bulb for luggage compartment light

Installing bulb for light

Note

Only use the relevant bulb specified in the bulb table →  IN IN - Bulb table and installation instructions -
"Information" chapter.

Installing bulb for light

1. Insert new bulb into the contact springs.

Installing luggage compartment light

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing bulb for light

4170

Luggage compartment light overview

D

- Luggage compartment light

Installing luggage compartment light

1. Attach plug on luggage

compartment light.

2. Press luggage compartment light into the luggage compartment lining.

997110, 997111, 997120, 997121, 997310, 997311, 997320, 997321, 997410, 997411, 997430, 997431,
997610, 997611, 997620, 997621

WARNUNG

Diagnostic system: reading out fault memory and activating systems

Installing luggage compartment light

4171

Gefahr des Verlusts der Text-Bild-Zuordnung beim Ausdruck.

Aus technischen Gründen kann derzeit nicht ausgeschlossen werden, dass trotz
einwandfreier Darstellung auf dem Bildschirm beim Ausdruck der
Zusammenhang von Text und zugehörigem Bild verloren geht.

•

Wird der Fehler nicht bemerkt, besteht die Gefahr, daß Arbeiten nicht korrekt
durchgeführt werden und es dadurch zu Personen- und Sachschäden kommt.

•

→ Vergleichen Sie deshalb nach dem Druckvorgang unbedingt die Ausdrucke mit der
Bildschirmdarstellung. Korrigieren Sie die Ausdrucke im Fehlerfall so, daß der Inhalt der
Bildschirmdarstellung zutreffend wiedergegeben wird.

WARNING

Danger of losing text-figure correspondence when printing out.

For technical reasons, it can currently not be ruled out that the correspondence
between text and associated figure can be lost when it is printed out, even though
the display on the screen is correct.

•

If the fault is not noticed, there is the danger that work will not be performed
correctly which can cause injury and damage.

•

→ Therefore, always compare printouts with the screen display after printing them out. Correct
the printouts if they are faulty so that the content of the screen display matches that on the
printouts.

AVERTISSEMENT

Risque de perte de la correspondance texte-illustration lors de l'impression papier.

Pour des raisons techniques, il ne peut pas être exclu à l'heure actuelle que, même
en cas d'affichage correct à l'écran, la correspondance entre le texte et l'illustration
puisse être erronée sur l'impression papier.

•

Si l'erreur passe inaperçue, on court le risque d'exécuter certaines opérations de
manière incorrecte pouvant conduire à des dommages corporels et matériels.

•

→ Comparez impérativement pour cette raison les impressions papier avec l'affichage à l'écran.
Corrigez-les en cas d'erreur de manière à reproduire correctement l'affichage à l'écran.

ATTENZIONE

Pericolo di perdita dell'abbinamento testo-immagine nella stampa.

Per motivi tecnici non è escluso che, nonostante la rappresentazione sullo schermo
risulti perfetta, durante la stampa venga persa la corrispondenza fra testo e
relativa immagine.

•

Se tale difetto non viene rilevato vi è il pericolo che i lavori non siano eseguiti
correttamente; ciò può avere come conseguenza lesioni e danneggiamenti.

•
