Porshe 911 (997). Manual - part 1000

Interior light overview

B

- Interior light

Removing interior light

1. Pull the interior light out of the trim panel carefully from the

front.

2. Release plug on interior light -arrow a- and pull it off.

Removing lens for interior light

Diagnostic system: reading out fault memory and activating systems

Removing interior light

4157

Removing lens for interior light

1. Carefully release lens at the three locking lugs on the interior light -arrow a- and remove interior

light.

Removing bulb for interior light

Removing bulb for interior light

1. Remove defective bulb from between the contact springs.

Installing bulb for interior light

Installing bulb for interior light

Note

Only use the relevant bulb specified in the bulb table →  IN IN - Bulb table and installation instructions -
"Information" chapter.

Diagnostic system: reading out fault memory and activating systems

Removing lens for interior light

4158

Installing bulb for interior light

1. Insert new bulb into the contact springs.

Installing lens for interior light

Installing lens for interior light

1. Insert interior light into the two guides on the lens.

2. Press interior light down until the three locking lugs click into place in the lens.

Installing interior light

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Installing bulb for interior light

4159

Interior light overview

B

- Interior light

Installing interior light

1. Connect plug for interior light until the plug engages

perceptibly.

2. Insert interior light into the trim panel at the rear, then press it into the trim panel at the front.

997110, 997111, 997120, 997121, 997310, 997311, 997320, 997321, 997410, 997411, 997430, 997431,
997610, 997611, 997620, 997621

WARNUNG

Diagnostic system: reading out fault memory and activating systems

Installing interior light

4160
